REPLACES: GARRETT GT3782VAS N/A

BLADES CONFIGURATION: 11+0

NOSE (A)(mm): 15.68

INDUCER (B)(mm): 56.83

EXDUCER (C)(mm): 82.04

EXTENDED TIP (D)(mm): 5.58

TIP HEIGHT (E)(mm): 5.58

SUPERBACK (F)(mm): 5.4

OVERALL HEIGHT (G)(mm): 49

BORE SIZE (H)(mm:) 7.48

ROTATION: Forward

BORE TYPE: Threaded-M7x1.0LHT

FITS ORIGINAL HOUSING: YES

MATERIAL: N/A

NOTES:
N/A
Performance Design
82

Fit Vehicles/Turbochargers: Ford 6.0L 2004.5-2007 Powerstroke 743250-0014
