Enhanced Turbo Audi Seat VW 721021 ARL GT1749MV Hybrid Turbocharger CHRA Cartridge



  • Description - PLEASE ENSURE YOU MATCH FROM YOUR PART NUMBER (DO NOT USE FRAME SIZE I.E. GTB22, K03, RHF5, TD04)
    This Buy It Now listing is for a BRAND New enhanced turbocharger CHRA to fit the following turbocharger:

    Audi A3
    Seat Ibiza
    Seat Ibiza Cupra
    Seat Leon
    Seat Leon Cupra
    Seat Toledo
    Volkswagen Bora
    Volkswagen Golf

    705650-0001
    716213-0001
    721021-0001
    721021-0006
    721021-0008
    742614-0001
    742614-0002
    742614-0003
    742614-0004

    ENGINE CODE:

    ARL

    BPX

    BPX Euro 3

    BUK

    PD UI



    VEHICLE OE NUMBER:

    03G253014G

    03G253016R

    03G253016RX

    038253016D

    038253016Q

    038253016Q V510

    038253016DX

    038253016G

    038253019G

    Contents:

    1 x Enhanced CHRA

    2 x Copper Oil Feed Washer

    1 x Oil Drain Gasket

    1 x Compressor Housing O Ring

    1 x Oil Syringe

    1 x High Speed VSR Balancing Certificate

    1 x Enhanced Turbo Sticker

    This Turbo CHRA is built and fully high-speed balanced in the UK in our own production facility by professional turbocharger engineers and is our Race specification.

    Specification:

    Spec: RACE

        New, uprated, lightweight Race Billet Compressor Wheel. Our Upgrade Billet Compressor Wheels are designed for performance use and enhance the airflow of the unit thanks to Increased Inducer Efficiency and Extended Exducer technology. Manufacturing this wheel from solid billet alloy via a computer controlled 5 axes CNC milling machine allows us to machine blades to the tightest of tolerances, reducing weight over the original wheel  and reducing spool times by up to 500rpm.

    New OE spec Seal Plate

    New OE spec Bearing Housing

    New OE spec Heat Shield

    New OE spec Turbine Shaft and Wheel

    New Heavy Duty Bearing pack

    Upgraded 360 Race Thrust Bearing

    Upgraded Race Thrust Collar

    Upgraded Total Closure Oil Seal Piston Ring

    Heavy Duty Journal Bearing

    Reverse Thread Shaft Nut

    High boost multi-stage precision balance.

    12 Months Parts & Labour Warranty

    FITMENT: Direct fit to original housings, no machining required, no modifications.

    PERFORMANCE INCREASE:Power = 10%  Strength approx 20%

    OTHER REQUIRED MODIFICATIONS: Fuelling check is required with adjustment where required. Unit will replace original standard turbocharger CHRA, although to maximise performance, upgraded breathing modifications are recommended (filter, zhaust, cooler etc).

    RATED POWER: 225HP*

    *rated power is based on 100% reliability. Although more power could be found by increase boost pressure, doing so will begin to affect reliability.

    Following fitment and remapping of an Enhanced Turbo, if your Dyno run power figure tops our leaderboard, then we will refund £50 from your order! Simply send us a copy of your Dyno run, a spec of the vehicle and a picture, and we will show the world your pride and joy.

    WANT THE CHRA FITTING?

    If you want your turbo enhancing by the professionals, see below on how to purchase a CHRA Assembly Bolt On to your CHRA.

    ENHANCE MY TURBO

    Turbo CHRA Fitting add-on includes: failure analysis before full strip-down of supplied unit, professional cleaning of housings and actuator, fitment of Enhanced Turbo CHRA and boost calibration and postage back to you. Note: all parts being reused MUST be in a good working condition. Any repair work or replacement parts required will incur further costs which will be discussed as required with customer.

    Alternatively, contact us for a brand new, genuine OE Turbocharger enhanced to this specification.

    Turbo Rebuild are the professionals in the enhancement of production Turbochargers.

    Since the millennium, our experience in the repair of failed turbochargers, combined with the continuous development of power upgrades, remaps and easy access to rolling road Dynos, we have found many turbochargers simply cannot handle the performance that the engine requires.

    So what is an enhanced turbocharger? Do you mean a hybrid Turbocharger?

    Well, it’s a yes and no. An enhanced turbo is a unit that has been improved to provide maximum performance without compromising reliability. This in itself is indeed a hybrid turbocharger by definition, in that the turbocharger has been modified and upgraded. However, an enhanced turbo isn’t a full on fire-breathing hybrid turbocharger with enlarged wheels etc. If you’re chasing figures, then an enhanced turbo is not for you.

    An enhanced turbo maximises the potential of the OE Turbocharger and is ideally suited to applications where the vehicle has been tuned or remapped.

    So what do you actually offer?

    Turbo Rebuild can offer complete, brand new, enhanced turbochargers and also many enhanced Turbo CHRA, typically these come in 2 forms: Remap and Race

    REMAP

    Our Remap units are turbochargers that are enhanced to provide 100% reliability in applications where the vehicle has been remapped. These units require no remapping after fitting; they are 100% plug and play. Each Remap Enhanced Turbo is meticulously built by hand by one of our own time-served, professional turbocharger technicians. Specifications of the Remap range vary on each application, with typical upgrades including upgrade 360 race bearings, total closure oil seal piston rings and performance high-speed precision balancing.

    RACE

    Our Race units are turbochargers that are further enhanced to maximise the original turbocharger’s possible performance whilst ensuring 100% reliability. Our Race units will, in most cases, require a fuelling check with some minor adjustments possible to ensure both reliability and to maximise the performance. Most of our Race units flow over 10% more power than the original, faster spool and are more reliable than the original.

    We can also offer bespoke products depending on customer requirements.

    The development in our enhanced units has been extensive and time consuming, but we are confident that we offer the No. 1 solution for remapped vehicles to fix what is the weak point...

    Are these turbochargers good quality?

    This is the most asked question we get! All CHRA are built in-house by our own professional turbo technicians using OE quality aftermarket parts where OE is not available. Our component suppliers follow strict requirements for our products which include heat treating, complete finishing of all casting components, and drag reduction polishing of bearing faced components to reduce friction. All units are balanced in up to 3 stages to ensure the best possible balance, operation and reliability. Every single unit is quality controlled at multiple points in the production stage; we feel you cannot buy a better product, which is why we offer the following warranty.

    12 months unlimited mileage parts and labour warranty.

    Free extended 2 year parts warranty!*

    *Extended parts warranty covers any turbocharger internal component which has failed due to incorrect assembly or faulty component. Warranty does not cover damage caused by oil contamination, starvation, foreign object damage, using unit outside operating limits or damage caused due to damaged or faulty engine components.

     Free extended parts warranty to be undertaken solely by Turbo Rebuild.

    Unit must not be disassembled in any way before returned to Turbo Rebuild.

    A one-off labour charge of £100 plus VAT is applicable to all repairs.
