These unit are are assembled and balanced in our own UK workshops with quality aftermarket upgraded components from our Worldwide supply chain, and totally transforms the performance of the vehicle.

WARNING: This turbocharger features larger wheels and is not compatible with standard ECU calibrations or off-the-shelf maps/flash files. Use of this turbocharger requires a fully custom ECU calibration (custom/live mapping).

Failure to correctly custom-map the ECU may result in poor performance, ECU fault codes, and engine and/or turbocharger damage. Damage resulting from incorrect or absent ECU calibration is not covered under warranty.

All warranty claims are subject to return-to-manufacturer inspection. If an issue is determined to be caused by application, installation, or tuning rather than a manufacturing defect, warranty will be denied and any remedial work will be chargeable.

BRAND:

Enhanced Turbo

FITMENT:

This unit is designed and manufactured to fit the following vehicles:

BMW 135i/335i/535i/Z4 3.0L Petrol 2006-2014 including Touring and GT RIGHT HAND DRIVE ONLY.

49131-07000

49131-07001

49131-07005

49131-07006

49131-07007

49131-07008

49131-07009

49131-07015

49131-07020

49131-07021

49131-07025

49131-07026

49131-07027

49131-07028

49131-07029

49131-07030

49131-07031

49131-07050

49131-07051

49131-07061

49131-07065

49131-07066

49131-07067

49131-07160

49131-07161

49131-07181

49131-07205

49131-07206

49131-07207

49131-07208

49131-07209

49131-07210

49131-07225

49131-07226

49131-07227

49131-07228

49131-07229

49131-07240

4564710

4564712

7563685

7563687

7583863

7583865

7593015

7593017

7649289

454743001

456471001

756368503

756368703

758386301

759301501

759301502

759301503

759301504

11654555418

11654564710

11654564712

11654564713

11657563685

11657563687

11657563692

11657583863

11657583865

11657593015

11657593016

11657593017

11657593018

11657649289

SPECIFICATIONS:

To enable power outputs required and to ensure reliability, we upgrade the units as follows:

Compressor Wheel - Enlarged lightweight billet performance compressor wheel included small nose, increased inducer efficiency and extended tip technology

Turbine Wheel - Increased TD04 shaft thickness and enlarged turbine wheel (Hi Flow 9 Blade option also available)

Bearing Systems - Enlarged TD04 bearings, with increased oil flow, 360 degree Enlarged thrust pad, staggered gap oil seals

Wastegate - Stainless steel enlarged high temperature wastegate assemblies

Balancing - All units are 2 stage balanced with final balance undertaken at high speed in real world conditions to motorsport tolerance. This allows us to ensure not only the unit performs correctly, but also that no leaks are present nor is there excessive noise.  A balancing certificate is included with each Turbocharger.

WARNING:  ENLARGED 50mm/2" INTAKE PIPES ARE REQUIRED, STANDARD INTAKE PIPES WILL NOT FIT THESE TURBOCHARGER.  CUSTOM MAPPING IS ALSO REQUIRED FOR CORRECT OPERATION

         MAXIMUM BOOST PRESSURE 23Psi

CONTENTS:

1 x Pair of Enhanced ET-N54-600 Turbochargers (including actuator)

Installation Gaskets

Balancing Certificate

12 months warranty

IF YOU ARE UNSURE OF FITMENT ON YOUR VEHICLE, PLEASE CONTACT US AND WE WILL TRY TO ASSIST.
