Uprated Billet Hybrid Turbo CHRA Cartridge for the Land Rover T2 (T250) 452055- Turbochargers. This Hybrid Cartridge is built to order to the highest standard possible in our Lancashire workshop
A BRAND NEW DIRECT REPLACEMENT aftermarket Hybrid Turbo CHRA Cartridge for the Land Rover T2 (T250) Turbochargers.
These Hybrid CHRA are built by hand in our lancashire workshop to order to the highest standard possible.
We have developed this upgrade unit to use the Garrett GTX style compressor wheel, which although being a direct replacement for the OE cast wheel offers a reduction in spool time by around 500rpm thanks to the 11 blade design and the super light weight. Also airflow is higher than the standard wheel thanks again to the 11 blades and also the small nose resulting in a larger blade area.
For those looking to increase the boost pressure, we have fitted a large pad 360 race thrust bearing and uprated high temperature step gap staggered rear oil seal.
This really is a bullet proof upgrade CHRA that bolts DIRECTLY into the OE housings without any modifications.
SPECIFICATIONS: Super lightweight machined from billet Small nose hub resulting in larger blade surface area Reverse thread shaft nut Large pad stainless steel thrust collar Latest high temperature heavy duty journal bearings 360 Race thrust bearing with large pad thrust Step gap high temperature rear oil seals High speed VSR trim balanced Max advised boost 22psi
