A brand new, uprated CHRA Cartridge for the Astra VXR. Built and balanced in our Lancashire workshop.
This CHRA Bolts directly in place of the standard unit. No modification is required. Simply unbolt the old CHRA and fit the ULTIMATE VXR CHRA.
Pushing the limits in the VXR world, our latest CHRA really is something else. Being a direct fit to the standard Turbo Manifold and compressor housing, yet more powerful than ANYTHING seen in the standard OE housings, this really is the must have!
This CHRA is specced, built and balanced by Turbo Rebuild and has been tested to the limits... and we haven’t broken it yet!
Vauxhall Astra VXR (H) 2004-2009
Vauxhall Zafira VXR 2005-2010
Vehicle OE Number:
New, uprated, lightweight Race Billet Compressor Wheel. Our Upgrade Billet Compressor Wheels are designed for performance use and enhance the airflow of the unit thanks to Increased Inducer Efficiency and Extended Exducer technology. Manufacturing this wheel from solid billet alloy via a computer controlled 5 axes CNC milling machine allows us to machine blades to the tightest of tolerances, reducing weight over the original wheel and reducing spool times by up to 500rpm.
New OE spec Seal Plate
New OE spec Bearing Housing
New OE spec Heat Shield
New OE spec Turbine Shaft and Wheel
New Heavy Duty Bearing pack
Upgraded 360 Race Thrust Bearing
Upgraded Race Thrust Collar
Upgraded Total Closure Oil Seal Piston Ring
Heavy Duty Journal Bearing
Reverse Thread Shaft Nut
High boost multi-stage precision balance.
12 Months Parts & Labour Warranty
FITMENT:Direct fit to original housings, no machining required, no modifications.
315BHP* and a DIRECT FIT to your standard housings!
This Turbo CHRA is built and fully high-speed balanced in the UK in our own production facility by professional turbocharger engineers and is our Race specification.
Turbo Rebuild are the professionals in the enhancement of production Turbochargers.
Since the millennium, our experience in the repair of failed turbochargers, combined with the continuous development of power upgrades, remaps and easy access to rolling road Dynos, we have found many turbochargers simply cannot handle the performance that the engine requires.
At Turbo Rebuild we do as our name says... enhance turbochargers.
So what is an enhanced turbocharger? Do you mean a hybrid Turbocharger?
Well, it’s a yes and no. An enhanced turbo is a unit that has been improved to provide maximum performance without compromising reliability. This in itself is indeed a hybrid turbocharger by definition, in that the turbocharger has been modified and upgraded. However, an enhanced turbo isn’t a full on fire-breathing hybrid turbocharger with enlarged wheels etc. If you’re chasing figures, then an enhanced turbo is not for you.
An enhanced turbo maximises the potential of the OE Turbocharger and is ideally suited to applications where the vehicle has been tuned or remapped.
So what do you actually offer?
Turbo Rebuild can offer complete, brand new, enhanced turbochargers and also many enhanced Turbo CHRA. Typically these come in 2 forms: Remapand Race
Our Remap units are turbochargers that are enhanced to provide 100% reliability in applications where the vehicle has been remapped. These units require no remapping after fitting; they are 100% plug and play. Each RemapEnhanced Turbo is meticulously built by hand by one of our own time-served, professional turbocharger technicians. Specifications of the Remap range vary on each application, with typical upgrades including upgrade 360 race bearings, total closure oil seal piston rings and performance high-speed precision balancing.
Our Race units are turbochargers that are further enhanced to maximise the original turbocharger’s possible performance whilst ensuring 100% reliability. Our Race units will, in most cases, require a fuelling check with some minor adjustments possible to ensure both reliability and to maximise the performance. Most of our Race units flow over 10% more power than the original, faster spool and are more reliable than the original.
We can also offer bespoke products depending on customer requirements.
The development in our enhanced units has been extensive and time consuming, but we are confident that we offer the No. 1 solution for remapped vehicles to fix what is the weak point...
Are these turbochargers good quality?
This is the most asked question we get! All enhanced turbochargers start life as a genuine OE Turbocharger. This ensures the best possible starting point for quality. From here, we carefully disassemble the turbocharger, and upgrade the units with our performance-proven products. The final creation is then precision high-speed balanced on one of our own in-house VSR balancing machines to far tighter tolerances than the original turbocharger, which ensures maximum reliability. Each unit is also extensively tested for oil leaks, vibrations, excessive noise and spool ramp before dispatch.
All CHRA are built in-house by our own professional turbo technicians using OE quality aftermarket parts where OE is not available. Our component suppliers follow strict requirements for our products which include heat treating, complete finishing of all casting components, and drag reduction polishing of bearing faced components to reduce friction. All units are balanced in up to 3 stages to ensure the best possible balance, operation and reliability. Every single unit is quality controlled at multiple points in the production stage; we feel you cannot buy a better product, which is why we offer the following warranty.
12 months unlimited mileage parts and labour warranty (CHRA only - does not over ancilliary costs).
Free extended 2 year parts warranty!*
*Extended parts warranty covers any turbocharger internal component which has failed due to incorrect assembly or faulty component. Warranty does not cover damage caused by oil contamination, starvation, foreign object damage, using unit outside operating limits or damage caused due to damaged or faulty engine components.
Free extended parts warranty to be undertaken solely by Turbo Rebuild.
Unit must not be disassembled in any way before returned to Turbo Rebuild.
A one-off labour charge of £100 plus VAT is applicable to all repairs.
NOTE: This CHRA is NOT suitable on a standard engine without being remapped. The greater airflow produced by this CHRA will cause a standard engine to run lean which can result in engine failure. To obtain maximum power, engine will need modification to fuel system (pump, injectors, ECU remap), Exhaust, Air Filter, Intercooler etc. Please consult your Tuner.
Turbo Rebuild cannot be held responsible for damage caused by incorrect fitting or by running without being professionally remapped and set up to ensure boost and fuelling are correct.
