This is a BRAND NEW Turbocharger Turbine Shaft and Wheel.

This turbo turbine shaft and wheel is made using only the finest materials to make sure it matches or exceeds the standards of the original.

BRAND:    AFTERMARKET

QUALITY : OE

OE SHAFT & WHEEL NUMBER:

INDUCER DIAMETER (A): 35.83mm

EXDUCER DIAMETER (B): 23.90mm

TIP HEIGHT (C): 3.45mm

JOURNAL BEARING DIAMETER (D): 6.26mm

COMPRESSOR WHEEL BORE: 4.40mm

BLADES: 9

SLENDER/STRAIGHT SHAFT: Straight

PISTON RING: Single

BACK FACE TYPE: Open

BALANCED: Yes

This turbo turbine shaft and wheel fits the following OE turbo part numbers::

VZ35

VZ39

VZ48

VZ58

13900-81AB4

13900-78GA4

13900-65H61

13900-76GA7

Suzuki

Average dispatch: 24 Hours

**PHOTO FOR ILLUSTRATION PURPOSES ONLY**

THE USE OF MANUFACTURERS NAMES, PART NUMBERS AND SYMBOLS ARE FOR THE USE OF REFERENCING ONLY AND DO NOT IMPLY THE PART IS MADE BY THE SAID MANUFACTURER.

ALTHOUGH WE MAKE OUR GREATEST EFFORTS TO ENSURE ALL OUR TURBO PRODUCTS ARE DESCRIBED CORRECTLY INCLUDING FITMENT INFORMATION AND DIMENSIONAL REFERENCES, WE CANNOT GUARANTEE THESE TO BE CORRECT AS MISTAKES CAN HAPPEN. WE WILL NOT BE HELD FOR ANY DISCREPANCIES DISPLAYED.
